AstralPool Viron Connect 10 Automation System

Accessories

• Touchscreen wireless receiver (10016) and Equipment-side transceiver (10017) together allows the touchscreen to be relocated inside the house without needing a cable to be run. The equipment-side transceiver is installed near the pool equipment and a RF signal is used to communicate with the touchscreen wireless receiver. This can be mounted somewhere near where the touchscreen is to be mounted in a position that will receive sufficient signal.
• Waterproof hand-held remote (15205). Requires Hand-held remote RF receiver (10019).
• Internet Gateway (10030) is required to control the Connect 10 by the internet or by the mobile apps.
• Connect 10 temperature and solar sensor kit (520146) allows the Connect 10 to measure the pool temperature and control pool heaters.
• Where solar heating is used, you can add a Connect 10 Solar modulator lead (15211 - 3m, 15212 - 20m and 15213 - 50m) to be installed on the roof as roof (or hot) temperature sensors. Requires Connect 10 Temperature and solar sensor kit (520146).

Note: Requires installation by a licenced electrician. Required to be hard-wired to a circuit rated to a minimum of 32 amps, ideally 40 amps. Maximum load is 40 amps.
